10A 250V dc type general purpose power relay
10A 250V dc type general purpose power relay
- Contact from: 2Z
- Contact capacity:10A 220VAC/ 28VDC
- Coil Votage:6~110VDC 6~240VAC
- Coil Power:1.5W
- Contact Resistance≤100mΩ
- Insulation Resistance≥500mΩ
power relay 24v
60vdc power relay
2.SPECIFICATION
| Type | 70.2 |
| Contact type | 2Z |
| Contact overload | AC 10A 250V DC 10A 30V |
| Rated coil power | ≤50mΩ |
| Insulation resistance | ≥500 mΩ |
| Dielectric strength | BOC 1500VAC
BCC 1500VAC |
| Coil nominal power | AC 6 to 380v
DC 6 to 220V |
| Coil nominal power | AC 2.0VA to 2.8VA
DC ≤1.5W |
| Operating temperature ℃ | -40~+60℃ |
| weight(G) | ≤85 |
| Mounting | Outlet |
| Type | 70.3 |
| Contact type | 3Z |
| Contact overload | AC 10A 250V DC 10A 30V |
| Rated coil power | ≤50mΩ |
| Insulation resistance | ≥500 mΩ |
| Dielectric strength | BOC 1500VAC
BCC 1500VAC |
| Coil nominal power | AC 6 to 380v
DC 6 to 220V |
| Coil nominal power | AC 2.0VA to 2.8VA
DC ≤1.5W |
| Operating temperature ℃ | -40~+60℃ |
| weight(G) | ≤85 |
| Mounting | Outlet |
3.COMPANY INFORMATION
